ZJ1000
In the world of boating, stability has always been a crucial factor. Enter the new - generation gyro boat stabilisers, a game - changing innovation that is set to redefine the way boats move on water.
Gyro boat stabilisers are sophisticated devices that utilize the principles of gyroscopic motion to counteract the rolling and pitching of boats. These stabilisers work by spinning a high - speed rotor within a gimbal system. As the boat experiences movement due to waves or other external forces, the gyroscopic effect of the spinning rotor generates a force that actively resists the unwanted motion, providing a significantly smoother ride.
One of the key advantages of these gyro boat stabilisers is their adaptability. They can be installed on a wide range of boat sizes, from small pleasure crafts to large yachts. This versatility means that boat owners across the spectrum can enjoy the benefits of enhanced stability. Whether it's a family out for a day of cruising or a serious sailor on a long - distance voyage, the gyro stabilisers can make a world of difference.
Manufacturers have been investing heavily in research and development to improve the efficiency and performance of these stabilisers. The latest models are not only more effective at reducing boat motion but are also more compact and energy - efficient. This is a major plus, as it allows for easier installation without sacrificing valuable space on the boat, and also reduces the strain on the boat's power supply.
In addition to improving the comfort of passengers, gyro boat stabilisers also have safety implications. By reducing the roll and pitch of the boat, they can enhance the vessel's overall stability in rough seas, reducing the risk of capsizing and making it easier for the crew to handle the boat.
For the boating industry, the introduction of these advanced gyro boat stabilisers represents a significant step forward. It is expected to attract more people to boating, as the smoother rides offered by these stabilisers will appeal to those who may have been deterred in the past by the discomfort associated with a rocking boat.
As more boat owners and operators become aware of the benefits of gyro boat stabilisers, it is likely that we will see a widespread adoption of this technology in the coming years. The future of boating is looking steadier and more enjoyable, thanks to these remarkable gyroscopic devices.
SIZE DOES MATTER
WHICH MODEL SIZE IS RIGHT FOR YOU?
No one knows more about how you boat than you! Please contact us and we will guide you to choose the right model for you!
SIZE DOES MATTER
Stabilization for Small Boats
Exceptional Stabilization Performance
It detects boat posture and adaptively controls it. This ensures superior stabilization in unpredictable waves, reduce up to 96% of the boat roll.
Innovative Architecture
Our patented mechatronic torque control system is hydraulic components-free, known for its robustness and durability. it minimizes failures and offers easy maintenance.
Advanced Triple Buffer Protection
Combining mechanical, electromagnetic and electronic buffering, the system is designed to withstand impacts, ensuring reliability even in the most challenging sea conditions. This design is also protected by multiple patents.
View our product details
Weight
Dimensions
30000KGS
3700*4000*2020mm
Gyro System
This includes the flywheel and its base. The flywheel, placed vertically in a sealed casing, connects to the base via a side shaft and bearings. lts high-speed rotational movement produces anti-roll torque during procession, which helps reduce ship sway.
Drive System
Consisting of a servo motor and a servo motor controller, the servo motor adopts a frame-less structure and directly drives the flywheel shaft, ensuring high transmission efficiency while also having the advantage of a compact structure.
Cooling System
Featuring a water tank, cooler, water pump, piping, and antifreeze, this system uses the cooler to exchange heat with seawater, subsequently cooling critical components like bearings, motors, and electronic controls.
Detailed parameters
| Model | ZJ1000 |
|---|---|
| Applicable Boat Range | Full Load Displacement≤2100Tons |
| Rated RPM | 1800 rpm |
| Angular Momentum | 1000 kNms |
| Anti-rolling Torque | 2800 kNm |
| Time to Rated RPM | 50 min |
| Time to Stablization | 25 min |
| Start-up Power | 2～150 kW |
| Operating Power | 70～110 kW |
| Power Input | 3PH AC380V 120 kW |
| Weight | 30000KGS |
| Overall Size (L*W*H) | 3700*4000*2020mm |
| Installation Space (L*W*H) | 4700*5000*2120 mm |
| Cooling Method | Raw Water-cooled 60L/min |
| Ambient Temperature | -20℃～60℃ |
| Noise Output @ 1 meter | ≤75 dB |
| Protection Rating | IP65 |
| Control Panel | 5-inch Touch Screen |
